Showcases

Ethercat

# Ethercat

CC100 to extern IP20 Ethercat slaves

Online Table

Create your table direct from codesys.
High dynamic changes from attribute, like visible, color, values.

Gauge

GAUGE direct & remote controlled

Combined Controls

Combined Control
usefull for automation building

Controls Elements

Alarm

Display Info/Warning/Alarms with Details

Demo

Explore all features of PLCVisu in conjunction with one PLC.

IO

Connect a VP400 to a PFC300 and a CC100 and interact with the connected devices from the VP400.

Trend

Runing on a VP400 and access to other PLC’s via iFrame.

TCP Modus

Communicate between PFC300 and CC100.

CC100 Serial Communication

This repository shows how the serial interface of the CC100 can be integrated into a Docker container (Node-RED). For this purpose, the WAGO Energy Meter (MID) is connected as an example. The communication between Node-RED and the MID is based on Modbus RTU.

Indexed access to array structures (Placeholders)

Extremely useful in buildings, ships, and more.

By selecting a room or a cabin, an index is already passed to the page to be opened in order to be able to assign the information to be displayed. This can be the type, such as standard cabin/double cabin, temperature, lighting, or anything that changes depending on your choice of parameters.

Please try it with our online control.
